Tungsten Wire Mesh

Large inventory, support customization

Company advantage: large inventory, can be delivered at any time, support special specifications special customization

Description

Tungsten wire mesh is made of tungsten wire with purity over 99.9%. Tungsten wire mesh has very high tensile strength. It has the highest melting point of all metals even at high temperature over 1650ºC. Among its properties are a melting point of 3410ºC, a low coefficient of thermal expansion and low vapor pressure at elevated temperatures, along with good electrical and thermal conductivity.

Meanwhile, tungsten wire mesh is highly resistant to corrosion, it has high density, sufficient electrical resistance, high modulus of elasticity low vapor pressure and low thermal expansion combined with good thermal conductivity.

Specification parameter:

Material: Pure tungsten wire

Mesh count: 2-200 mesh

Wire diameter: 0.018-2.03mm

Common size: 1x30m/roll, 1.22x30m/roll, 1.5x30m/roll or others by your demand making it

Applications:

Vacuum heat furnace, heating elements, heat treatment supporting wire mesh.

Tungsten wire mesh is often used for its good conductivity for heat and electricity as well as for its high absorption capacity for radioactive radiation and X-rays. Tungsten wire cloth is used for battery, chemical, mine, hydrogen making, acid making, basic industry.

Packing: waterproof paper with plastic cloth,then put into wooden box.
